Using cluster.exe with Hyper-V 2012 R2

I have a newer 2012 R2 Failover Cluster on which I was not able to move one of the Cluster Shared Volumes. I kept getting an error indicating that no other node could own the CSV:

Error draining node / moving CSV to another node
Error draining node / moving CSV to another node
"Error Code: 0x80071398 The operation failed because either the specified cluster node is not the owner of the group, or the node is not a possible owner of the group"

So I searched online and found website after website indicating that I needed to use cluster.exe in order to add my second node as a possible owner of the CSV, with the following syntax:

cluster resource “csv_a1” /listowners

I was not able to use cluster.exe and eventually found that it had been deprecated.

Error when running cluster.exe in Server 2012 R2
Error when running cluster.exe in Server 2012 R2

It took me a while of searching and using the wrong PowerShell cmdlets to find this post on Installing the Failover Cluster Feature and Tools in Windows Server 2012

In the blog post it indicates that you can install the Windows Feature RSAT-Clustering-CmdInterface which “Includes the deprecated cluster.exe command-line tool for Failover Clustering. This tool has been replaced by the Failover Clustering module for Windows PowerShell.”

Well I already had the Failover Clustering module for Windows PowerShell installed, and I couldn’t figure out how to make this second node a possible owner of the CSV, so I installed RSAT-Clustering-CmdInterface to use cluster.exe

Installing RSAT-Clustering-CmdInterface to use cluster.exe
Installing RSAT-Clustering-CmdInterface to use cluster.exe

Once this was installed I was able to use cluster.exe to add my second node as a possible owner of “csv_a1”. Then I could drain the Node, and finally reboot it which was what I was trying to do before running into this issue.

Hopefully this helps someone else with Windows Server 2012 R2 Hyper-V Failover Clustering if they have this issue and are also getting errors when trying to use cluster.exe

Rename Ethernet Adapter in Server 2012 R2

I was having trouble renaming my single Ethernet adapter because I had added and removed the NIC a few times during VM testing. The name of the NIC in Network and Sharing Center was “Ethernet 2” and I wanted it to be named “Ethernet”. I like things neat.

When I tried to rename the adapter I got an error stating that there was already an adapter with that name. I knew I only had one virtual NIC attached to this VM so I knew it had to be a leftover somewhere.

I tried to use PowerShell to rename the adapter but had no luck – it also indicated that “Ethernet” was already in use.

I did a search on the registry for “Ethernet” and after some digging found what I was looking for:

Computer\HKEY_LOCAL_MACHINE\SYSTEM\ControlSet001\Control\Network

In a subkey of the Network key I found “Ethernet” and deleted it. Then I rebooted and was able to rename my “Ethernet 2” to “Ethernet”.

Registry setting after rename operation
Registry setting after rename operation

SSH and power settings on a ShoreTel 480g

Ever since deploying our new ShoreTel 480g phones I have been noticing that the 480g screens both dim after some time and go blank during certain times of day.

Our company has certain departments that are open from 08:00 to 21:00 which was interfering with this “sleep schedule” so I turned to the ShoreTel 14.2 Maintenance Guide because I had previously read somewhere that you could change the screen dimming on the phones. It turns out that there are default hours where the phone does go to sleep (outside the hours of 06:00 to 19:00 as long as the phone has been idle).

I wanted to check the current settings on the phones so I attempted to SSH into my phone. Connecting successfully was somewhat challenging but I was able to log in after a few minutes of searching the Internet and some help from our ShoreTel partner.

Whenever I typed in anonymous (the default ShoreTel user name for most things) to log in to the phone’s IP address I would get an error:

The fatal error from PuTTY
The fatal error from PuTTY

So I found that I should use the private key from my ShoreTel Director server in order to authenticate with the phone.

This private key is located in Shoreline Data\keystore\ssh and the file name is hq_rsa – you will also see the public key there hq_rsa.pub. I tried this key but it did not work.

I made a copy of the private key and used PuTTYgen to convert the key to something PuTTY could use, then browsed to that key in PuTTY Configuration | Connection | SSH | Auth | Authentication parameters. After connecting again, I could log in but this time as “admin” instead of anonymous.

Once logged in I ran the command getcfg power:

Default power values for the ShoreTel 480g
Default power values for the ShoreTel 480g

This gave me the current (default) power values on the 480g. My phones go idle after 5 minutes and sleep after 60 (as long as it is not 06:00-19:00 Mon-Fri).

I ended up creating a custom phone config file which only my phone would download in order to test some new settings. The template for the custom phone config file is C:\inetpub\ftproot\phoneconfig\custom_MAC.txt

My file name was custom_00104936d06c.txt

The text file was initially blank but I added the following parameters which I pulled from the Maintenance Guide:

idleBrightness (the intensity of the phone backlight when the phone is idle)
idleTimeout (the number of minutes without key presses or calls before the backlight dims)
sleepTimeout (the number of minutes without key presses or calls before the phone goes to sleep – screen turns off)
sleepInhibitStartTime (the beginning time of day when sleep is prevented)
sleepInhibitStopTime (the end time of day when sleep is prevented)

The contents of custom_00104936d06c.txt after editing (for testing purposes):

# Please consult Shoreline support before editing or deleting this file
[power]
idleTimeout=1
idleBrightness=50
sleepTimeout=5
sleepInhibitStartTime=18:00
sleepInhibitStopTime=21:15

So outside the hours of 18:00 to 21:15 this would cause the backlight to dim 50% after 1 minute and cause the screen to turn off after 5 minutes.

In order to apply this, I saved the file and rebooted the phone. Then I connected with a new PuTTY session and ran getcfg power again to see the new values:

My test power settings
My test power settings

Now my phone’s screen will dim after 1 minute of being idle, and it will sleep after 5 minutes of being idle.

After doing this testing I changed the parameters to match what the organization would need to use. After verifying that the settings applied successfully, I then changed the custom_IP480g.txt file to match. The only thing left was to reboot all phones for the settings to take effect.

The final config:

# Please consult Shoreline support before editing or deleting this file
[power]
idleTimeout=15
idleBrightness=10
sleepTimeout=30
sleepInhibitStartTime=07:45
sleepInhibitStopTime=21:15

Final custom power settings for 480g
Final custom power settings for 480g

Hyper-V Live Migration Error

A while back I encountered this error when trying to Live Migrate a VM from my Hyper-V 2012 Cluster to the new Hyper-V 2012 R2 Cluster.

You might  be asking why I was running Hyper-V 2012 in the first place…

I just happened to start upgrading our Hyper-V 2008 R2 Cluster after Windows Server 2012 was released, and then Windows Server 2012 R2 was released with some very much improved features. So I had a few VMs on the 2012 Cluster that needed to be moved to 2012 R2. It was a great time-saver to be able to Live Migrate from 2012 –> 2012 R2 (well, if I could get it working).

The error message when trying to LM a VM:

"The virtual machine cannot be moved to the destination computer. The hardware on the destination computer is not compatible with the hardware requirements of this virtual machine. Virtual machine migration failed at migration source."

I found this one fairly easily but it took a little bit of time.

When comparing my 2012 node to my 2012 R2 node I noticed that the Virtual Switches were named differently. Apparently for Live Migration this will cause an issue, at least in 2012 –> 2012 R2.

After renaming the Virtual Switches to match, the Live Migration completed successfully:

A Happy Live Migration
A Happy Live Migration

Safe Senders GPO Not Working

We had a GPO for Safe Senders in Outlook that was supposed to pull the Safe Senders from a text file shared on the SYSVOL, but it was not working.

I looked into Exchange 2010 to figure out how I could do Safe Senders at a server level rather than have to configure a GPO for it.

In the Exchange 2010 Management Console I navigated to Organization Configuration | Hub Transport | Transport Rules

Exchange 2010 Management Console - Transport Rules
Exchange 2010 Management Console – Transport Rules

On the Transport Rules tab I added a New Transport Rule:

Adding a new Transport Rule to Exchange 2010
Adding a new Transport Rule to Exchange 2010

When the wizard launches, it is very self explanatory and is built like an Outlook rule.

New Transport Rule Wizard
New Transport Rule Wizard

I selected to enable this new transport rule for the condition “when the From address matches text patterns” so I could add the domains I wanted to whitelist.

textpatterns

I added appriver.com$ as my text pattern. I used a dollar sign at the end of the text pattern because of what I read on TechNet:

The dollar sign ( $ ) character indicates that the preceding pattern string must exist at the end of the text string being matched. For example, contoso.com$ matches adam@contoso.com and kim@research.contoso.com, but doesn’t match kim@contoso.com.au.

Since I know that everything I want to whitelist from AppRiver comes from @appriver.com I use the $ character in my text pattern.

After clicking OK and then Next, it’s time to figure out what Action to perform when a message matches this text pattern.

What do we want our Transport Rule to do?
What do we want our Transport Rule to do?

I chose “set the spam confidence level to value” and then clicked on the underlined blue text link in order to set the SCL to -1. This ensures that Outlook does not classify the message as spam and put it in the Junk E-mail folder.

On the next page of the wizard I did not enter any Exceptions because I want this transport rule to be active for all messages coming in to my organization from AppRiver.

Now the rule is complete. But as always, there are other ways to do it rather than using the GUI. As in most cases, you can use PowerShell!

This is the output that we see on the last page of the New Transport Rule Wizard, which we can translate into a PowerShell command:

Name: 'Safe Senders'
Comments: ''
Priority: '0'
Enabled: $true
FromAddressMatchesPatterns: 'appriver.com$'
SetSCL: '-1'

Translated into a working PowerShell command:

New-TransportRule -Name "Safe Senders" -Comments 'Safe Senders list to whitelist specific domains' -FromAddressMatchesPatterns: 'appriver.com$' -SetSCL: '-1'

Since I already had this rule set up, I modified the string to create a test transport rule:

New-TransportRule -Name "Safe Senders Test" -Comments 'Test List Made From Powershell' -FromAddressMatchesPatterns: 'ericrdu.com$' -SetSCL: '-1'
Creating a New Transport Rule via PowerShell
Creating a New Transport Rule via PowerShell

If you don’t want to enable your new Transport Rule right away, add in -Enabled $false to your command. Otherwise the rule will be enabled by default.
You can also add a -Priority X (where X is a number) to set the order in which your rules will be applied. Since this is my first rule, I do not need a Priority and the default will be 0. Any additional rules will be added as +1.

So now, does the rule actually work?

Held Spam Report email header from earlier in the day, before the rule (because the Held Spam Report comes from AppRiver):

header1

Held Spam Report email header after adding the rule:

header2

Error Draining Roles in Hyper-V 2012 R2 Failover Cluster

I was trying to do some maintenance on my Hyper-V 2012 R2 Failover Cluster and I was unable to drain one of the nodes in order to install Windows Updates.

An error occurred pausing node 'RDU-HV01'
Error Code: 0x80071748
"The requested operation can not be completed because a resource has locked status"
I love specific error messages.
I love specific error messages.

In Hyper-V Manager the VM was stuck in a “Backing Up” status, and this was after I manually Live Migrated all other VMs to my second node.

status-backing-up

When trying to manually Live Migrate this VM I was prompted to override the locked resources and try again… and just like any good System Administrator I saw an opportunity to try and force something to work, while potentially producing an extremely horrible outcome, so I naturally clicked “Yes”. YOLO.

The virtual equivalent of kicking the computer.
The virtual equivalent of kicking the computer.

But it still failed with an error!

Failed to Live migrate virtual machine 'VM_name'
The action 'Move' did not complete.
Error Code: 0x80070057
The parameter is incorrect
#fail
#fail

I restarted the VM but that had no effect so I shut it down.

Now that the VM was shut down I could restart the node which I did from a command prompt utilizing the shutdown command. However the node would not restart – it was stuck somewhere in the shutdown process. I could still see it in Server Manager and when I did a systeminfo from the command prompt the System Boot Time told me that it had not restarted yet. Since I was doing this remotely, I could not go into the server room to shut down the server and I had no OoB management configured so I had to do a little digging. I found that others with this issue were able to fix it by restarting the Hyper-V Virtual Machine Management service. I tried stopping this service (vmms is the Service Name) from Server Manager of my Windows 8.1 laptop but it did not seem to work.

I then opened a command prompt to try using SC.exe to stop or restart the vmms service. By the time I figured out the correct syntax, I noticed that the node had just gone down for a restart. Maybe it timed out, or maybe my command from Server Manager just took a minute to go through.

The correct syntax would have been:

sc \\rdu-hv01 query vmms
sc \\rdu-hv01 stop vmms

The VM which was stuck in the “Backing up…” state was automatically moved to my second node and the first node restarted itself. The VM which was stuck started properly on the second node and the status for “Backing up…” was no longer showing.

Once the first node came back up from its restart I was able to Pause and Drain Roles to go on with my maintenance.

If this happened again I would suggest shutting down the VM which is stuck in the “Backing up…” status. Then Live Migrate everything else (don’t forget your storage!) so that the only thing on this node is the VM that is off. I would then attempt to restart the vmms service. If that does not work, restart the node.

Slow Network Performance on Server 2012 R2 Core

In going through the motions of upgrading our Hyper-V cluster from 2008 R2 to 2012 R2, I had originally started to deploy a Hyper-V 2012 cluster. While learning more about 2012 R2, I realized that there is no real way to upgrade a Hyper-V cluster, so I would need to burn down our 2012 cluster completely in order to use that hardware to create a 2012 R2 cluster. I wanted the new functionality of 2012 R2, and had not migrated more than a couple of VMs to the 2012 cluster, so I evicted one node from the 2012 cluster and installed 2012 R2. The VMs on the 2012 cluster were living on the single node in the 2012 cluster of one node.

Once I had the new node (a Dell PowerEdge R620 with 128 GB of RAM) running Server 2012 R2 Core Edition, I performed the initial setup of configuring the server properties with sconfig, configuring network settings using PowerShell, joining the server to the domain, running Windows Updates, installing Corefig, installing EMC software such as PowerPath and the Navisphere Agent, and a few other things to prepare the server for deployment.

I even created my new 2012 R2 cluster at this point, even though it was not needed quite yet since there was only one node running with Server 2012 R2.

After everything was ready for deployment, I created a test VM running Server 2012 R2. Since we run Server Core edition I used a 2012 R2 VM in my 2008 R2 Failover Cluster to manage the new node, using Hyper-V Manager to create the VM. Once the test VM was ready to be sent into “test production” I closed the Console connection and used Remote Desktop Connection to log on to my new VM.

I noticed that the performance of the VM via RDP was very slow. Even my RDP sessions to a remote site were better than my RDP session to this test VM which was in the server room at the main office (which was where I was). Doing a simple test by pinging the server came back with poor results. Pinging the node on which this VM was running via the management interface was fine – all response times were between <1ms and 1ms.

The storage network (connectivity to my SAN via two 1GB NIC using EMC PowerPath via iSCSI) was performing fine. Ping was normal and data transfer speeds between the test VM and the SAN matched those between the node and the SAN, as well as those from my 2012 cluster VMs to the same SAN.

Something was obviously wrong, but what?

The first thing I tried was to make another VM from scratch and see if it had the same results when in a RDP session. The outcome was the same – poor performance.

I thought it might be a settings issue, so I compared all of the settings related to networking with my Server 2012 node which was the exact same hardware. The only difference was that it was running Server 2012 and my new node was running Server 2012 R2. I compared settings of VMs themselves, settings of the Virtual Switch attached to these VMs, and the NIC Teaming settings on the nodes. Only one setting was different and it was the “Load balancing mode” of the NIC team dedicated to Cluster traffic (all VM traffic). I changed this to match, but it had no effect.

I figured something might be wrong that I can’t see via the GUI, so I recreated all of the virtual networking components that were tied to this machine. Since this node was so new, there was no production system running on it and I was able to do this outside of an official maintenance window. I deleted the Virtual Switch and destroyed the NIC Team. I then rebuilt the networking and attempted a test – the same problem was occurring.

Every experienced IT Pro has been in this situation before. You have something going wrong and you’ve almost run out of ideas. But on the bright side, you’re probably going to learn something new…

Like I said, I was almost out of ideas.

My next troubleshooting steps included thinking about the physical components. I thought maybe a LAN cable was bad. I was going to test this by trying new cables, but I wanted to try something else first before getting physical.

After doing more research on NIC Teaming with Windows Server 2012 R2 and learning more about Teaming mode and Load balancing mode, I destroyed the NIC Team and recreated it once more for good measure. I noticed that when I recreated the NIC Team it took some time for the second NIC in the team to become Active. Whether or not this observation had any merit, it got me thinking on the right track:

DRIVERS!

Before I went down the road of troubleshooting drivers I wanted to try the test I had in mind, which was segregating the NICs and testing them individually. If it was a bad cable, I would be able to tell which one (if only one and not both) was having problems.

So I destroyed the NIC team again and assigned the NICs static IP addresses. I didn’t need to assign static IPs to run my test because DHCP was working, but I wanted to reinforce some PowerShell learning. I opted to give out static IP addresses and also disable the interfaces from registering with DNS.

I don’t want these interfaces registering in DNS because they will be the interfaces that are being used for Cluster traffic only; I will not be allowing the Host OS to use the network adapter (a Hyper-V Virtual Switch setting which I will disable). If the host registers these interfaces in DNS I could have some issues, so I opt to remove the DNS registration.

My saved PowerShell code for setting a static IP address:

#call network adapter by name
 $netadapter = get-netadapter -name "name of NIC"
 #disable dhcp on this network adapter
 $netadapter | set-netipinterface -dhcp disabled
 #set ipv4 address, subnet mask, type
 $netadapter | new-netipaddress -addressfamily ipv4 -ipaddress 192.168.1.100 -prefixlength 24 -type unicast

Then with help from this thread on TechNet I was able to prepare a script to disable DNS registration. I know how to do it with netsh:

netsh interface ipv4 set dnsservers name="name of NIC" source=static address=172.20.1.5 register=none

but I wanted to do it with PowerShell.

#get adapter configuration by adapter name (NetConnectionID)
 $na=Get-WMIObject Win32_NetworkAdapter -filter "NetConnectionID = 'name of NIC'"
 $config=$na.Getrelated('Win32_NetworkAdapterConfiguration')
 #display current settings for DNS registration
 $config|select DomainDNSRegistrationEnabled, FullDNSRegistrationEnabled
 #disable DNS registration
 $config|%{$_.SetDynamicDNSRegistration($false,$false)}

Now that I had my static IP addresses set, I did the ping test to each static IP.

They both came back perfect. The results were <1ms to 1ms for both endpoints. This cemented my belief that it was something to do with the NIC Team and/or the driver.

Immediately I remembered that NIC Teaming was now  “in the box” with Server 2012 (and 2012 R2) (AKA now officially supported by Microsoft).

This led me to believe that it might have some functionality issues due to it being a new feature in Windows Server. I decided that I would update the drivers of my network adapters to see if this would resolve the issue. Since Server 2012 R2 is still fairly new, I figured my Broadcom NICs probably need the latest OEM driver rather than the one that Windows Server 2012 R2 installed on its own.

I knew I had Broadcom NICs but I didn’t know exactly which model. I tried to view the Device Manager remotely, since we run Core Edition of Windows Server, but found out after a few hours of research that viewing the Device Manager remotely is no longer supported! (Cue Sad Trombone)

However I did learn that you can get the same Device Manager information via PowerShell:
http://blogs.technet.com/b/wincat/archive/2012/09/06/device-management-powershell-cmdlets-sample-an-introduction.aspx

After installing the Device Management PowerShell cmdlets and trying to figure out how to get the information I wanted, I resorted to using Corefig. I was already about two hours in just trying to figure out what NICs I had in the server. I had contemplated changing over to GUI mode in order to run Device Manager, but I really did not want to have to go that far.

By using Corefig, I was able to view the “System Information” and look at hardware components to find information about the network adapters and what driver they were currently using.

Notes from Beyond The Post: Little did I know I could have opened System Information by typing “msinfo32” in the command prompt.

The driver file is b57nd60a.sys so I looked that up on the Internet and it led me to http://www.broadcom.com/support/ethernet_nic/netxtreme_server.php

I scrolled down to “Windows 2012-R2 (x64)” and saw that the latest driver version is 16.2.0.4

The driver listed in “System Information” was old – version 15.6.0.10

Copy/Paste output from “System Information”:

Name [00000010] Broadcom NetXtreme Gigabit Ethernet
 Adapter Type Ethernet 802.3
 Product Type Broadcom NetXtreme Gigabit Ethernet
 Installed Yes
 PNP Device ID PCI\VEN_14E4&DEV_165F&SUBSYS_1F5B1028&REV_00\000090B11C1DBA1D00
 Last Reset 2/18/2014 10:16 AM
 Index 10
 Service Name b57nd60a
 IP Address Not Available
 IP Subnet Not Available
 Default IP Gateway Not Available
 DHCP Enabled No
 DHCP Server Not Available
 DHCP Lease Expires Not Available
 DHCP Lease Obtained Not Available
 MAC Address ‪90:B1:1C:1D:BA:1D‬
 Memory Address 0xD91A0000-0xD91AFFFF
 Memory Address 0xD91B0000-0xD91BFFFF
 Memory Address 0xD91C0000-0xD91CFFFF
 IRQ Channel IRQ 4294967266
 …
 …
 IRQ Channel IRQ 4294967242
 Driver c:\windows\system32\drivers\b57nd60a.sys (15.6.0.10, 444.20 KB (454,864 bytes), 8/1/2013 8:34 PM)

So I downloaded the new driver and put it on the node in the C:\Drivers folder

I then used pnputil to install the driver.

I knew that I would get disconnected since I was doing all of this remotely, but if I wasn’t able to reconnect to the node I would just walk into the server room and hop on the server with our KVM in the rack.

pnputil -i -a c:\drivers\broadcom_win_b57_x64\b57nd60a.inf

Yep, I got disconnected. But I knew my session would reconnect after the driver update completed (as long as things went well).

And it did!

Using pnputil to update the Broadcom drivers in 2012 R2 Core
Using pnputil to update the Broadcom drivers in 2012 R2 Core

Now the exciting part – did this work to fix the network performance??

Seriously. I was excited. This is the fun part of my job that I really enjoy. I quickly went to my Server 2012 R2 VM to manage the node remotely in order to build the NIC Team as quickly as possible. I used Server Manager on this management VM to launch “Configure NIC Teaming” and build my NIC Team. This time, I made my Load Balancing setting “Dynamic” after learning more about that setting.

In order to learn more about NIC Teaming Mode in Server 2012 R2 I used the “Windows Server 2012 R2 NIC Teaming (LBFO) Deployment and Management” guide.

According to section 3.4.3 of this guide (emphasis my own):

3.4.3 Switch Independent configuration / Dynamic distribution
This configuration will distribute the load based on the TCP Ports address hash as modified by the Dynamic load balancing algorithm. The Dynamic load balancing algorithm will redistribute flows to optimize team member bandwidth utilization so individual flow transmissions may move from one active team member to another. The algorithm takes into account the small possibility that redistributing traffic could cause out-of-order delivery of packets so it takes steps to minimize that possibility.
The receive side, however, will look identical to Hyper-V Port distribution. Each Hyper-V switch port’s traffic, whether bound for a virtual NIC in a VM (vmNIC) or a virtual NIC in the host (vNIC), will see all its inbound traffic arriving on a single NIC.
This mode is best used for teaming in both native and Hyper-V environments except when:
a) Teaming is being performed in a VM,
b) Switch dependent teaming (e.g., LACP) is required by policy, or
c) Operation of a two-member Active/Standby team is required by policy.

Once the NIC Team was built I went to Hyper-V Manager and opened the Virtual Switch Manager for the node in question. I then created my Virtual Switch that would carry VM traffic.

Hyper-V Virtual Switch Manager

Now that the Virtual Switch was created I added it to the VM itself and clicked Start.

Once the machine was online and accessible, I did a ping test just as I had done a long time ago (at this point it had been more time than I care to admit!) and SUCCESS! The pings were all between <1ms and 1ms!

Updating the Broadcom drivers to the latest version for Server 2012 R2 was the solution to my issue. I could not be happier to resolve this, as now I could go full steam into migrating our VM infrastructure from Hyper-V 2008 R2 to Hyper-V 2012 R2.

Just to verify everything, I used “System Information” again to look at the drivers post-update:

System Information after updating the Broadcom drivers
System Information after updating the Broadcom drivers

The Driver path here technically applies to the NIC above that is not seen, but the NIC is the same as the one that is shown (it is listed 8 times in “System Information” because I have two 4-port Broadcom NICs).

As always if you see any way I could have improved this process or have anything to add, please leave a comment below!



Server 2012 R2: Failed to enumerate objects

Error Applying Security in Windows Server 2012 R2
Error Applying Security in Windows Server 2012 R2: Failed to enumerate objects in the container. Access is denied.

I found a thread on TechNet about the issue and the OP (original poster) replied saying that it was a bug all along and it had been patched.

Well as I wrote on the TechNet thread, I am still having this issue on a fully patched 2012 R2 Standard server. I was able to work around it by using the local Administrator account to assign permissions, rather than using an account in “Domain Admins”.

This bug does not seem effect permissions when using the folders, as I am able to create/modify/etc.; it is only an issue when setting the permissions on the folder.

Here was my folder when logged on as user1, a member of Domain Admins:

Security tab of the Properties of the Images folder on my VM
Security tab of the Properties of the Images folder on my VM

As you can see, Domain Admins have “Full control” of this folder and should be able to set any permissions needed. But I kept getting the error in the screenshot at the beginning of this post.

After reading the thread I found on TechNet, I logged on as the local Administrator, went to the folder in question, and added the group I wanted to have access. I then made those permissions propagate to all subfolders and it went quickly and without error. So it works as local Administrator but not as a Domain Admin.

From what I can tell the issue is that Windows Server 2012 R2 cannot recognize that user1 has “Full control” of the folder because user1 is not listed explicitly in the ACL. Even though user1 is a member of “Domain Admins” who are in the ACL, it does not matter.

This seems like a bug to me, but at least there is a fairly easy workaround.

Using Notepad++ to add multiple users to a Distribution List

During the latest snowstorm here in Raleigh we had the need for a new distribution group so that we could communicate between a select group of people who were working from home.

I used PowerShell to create the Distribution Group with the New-DistributionGroup cmdlet

new-DistributionGroup -Name 'Remote Workers' -OrganizationalUnit 'mybiz.local/Groups/Distribution' -SamAccountName 'Remote Workers' -Alias 'RemoteWorkers'
set-DistributionGroup -Name 'Remote Workers' -RequireSenderAuthenticationEnabled $false
Sidenote: I set RequireSenderAuthenticationEnabled to $false because I wanted this group to be accessible to Internet emails. If I wanted it to be internal only, I would not bother with running this command. I learned quickly with Exchange 2010 that when a new distribution group is created it makes this value $true which prevents emails being sent to the group unless the user is authenticated (a member of your domain).

Now that the group was created, I needed to add approximately 30 users. Fortunately someone had created a spreadsheet detailing these particular users, with columns including:

Last Name, First Name, Mobile Number, Work Extension, Department, Title, Email Address

While I could use some Excel functions to make usernames out of Last Name + First Name, the easiest option here was to use all of the email addresses with a PowerShell command.

I copied the email addresses into Notepad++. To turn this into a PS cmdlet that we can run in the Exchange Management Shell we need to insert  the Add-DistributionGroupMember cmdlet before all of the email addresses. I could manually paste this on each line, but that would be annoying. And manual. After adding this to each line I also have to put a closing quotation mark at the end of each line to close the email address value. So if this was for 100 or 200 people, or even 1,000 people if your environment is that large, it would take a long time and a lot of keystrokes.

I would rather spend some time now figuring out how to automate this so that when I need to perform this in the future I can do it with ease. This is where the awesomeness begins!

Now that we’ve pasted our email address list into Notepad++ with each email address on its own line, follow these instructions to turn it all into lines of PowerShell code:

  1. Press CTRL + H to bring up the Replace window
  2. check off “Regular expression” at the bottom left
  3. put a caret ^ in the “Find what” field (this is the regular expression for “the beginning of each line”)
  4. in the “Replace with” field enter the following:
    Add-DistributionGroupMember -identity 'Remote Workers' -member "
  5.  Click “Replace All”

Your Notepad++ window should now like this:
Note that there is a quotation mark before each email address

Output after using Notepad++ "Replace All" to add code to each line
Output after using Notepad++ “Replace All” to add code to each line

We aren’t done yet, as we have to close each line with a quotation after the email address.

  1. In Notepad ++, put a dollar sign $ in the “Find what” field (this is the regular expression for “at the end of each line”)
  2. in the “Replace with” field enter a quotation mark “
  3. Click “Replace All”

Now you have a full line of PowerShell code that should look like this:

Add-DistributionGroupMember -identity 'Remote Workers' -member "user1@mybiz.com"

Copy the entire Notepad++ window and paste this into your Exchange Management Shell to add all these users to the distribution group:

Output of Exchange Management Shell after pasting in code from Notepad++
Output of Exchange Management Shell after pasting in code from Notepad++

Don’t forget to press Enter for the last line. Since there is nothing following it, the shell will not process the command automatically as it did with all the previous lines.

Check your distribution group to see that it has its new members and be on your way to the next IT solution!



Renaming Windows Firewall Rules with PowerShell

I had some rules that were set by default that were not “user friendly” so I wanted to rename them in order to be able to tell what they were without having to query.

I can use Get-FirewallRule with some parameters to see the rules in question:

get-netfirewallrule -displaygroup "remote desktop" | format-table name, enabled -autosize
Use get-netfirewallrule to view the current firewall rules
Use get-netfirewallrule to view the current firewall rules

Then I Mark (right click, “Mark”, select and press the “Enter” key to copy to clipboard) the GUID and get the name of that rule to see what it is:

Get-NetFirewallRule -Name {4F5F06CB-CA8A-4676-BDB3-4BBBC8E95481}
Viewing the details of the firewall rule in question
Viewing the details of the firewall rule in question

Then I rename the rule using the Rename-FirewallRule cmdlet, and query again to see the change:

rename-netfirewallrule -name "{GUID}" -newname "New name of firewall rule"
get-netfirewallrule -displaygroup "remote desktop" | format-table name, enabled -autosize
Renaming the firewall rule to match the DisplayName attribute
Renaming the firewall rule to match the DisplayName attribute

As it turns out, these rules are duplicates of the ones above – the only difference that I found was that they apply to different profiles. The rules with “user friendly” names were for the “Public” Firewall Profile, whereas the GUID rules were for “Domain” and “Private” Firewall Profiles. This is the way the Remote Desktop rules are added when you configure Remote Administration with sconfig. This relates to my previous post on “Installation Configuration: Hyper-V Server 2012“.

Differences between the builtin rule and the rule created when using sconfig
Differences between the builtin rule and the rule created when using sconfig





My tech blog
